Description

• Selection of narrow or wide jet and adjustment of direction by rotating the central cones
• Circular duct connection D200...500mm
• Possible to install in a duct one size smaller than the nominal device size

Function

The supply air is introduced into the space at high velocity. Rotating the central cones modified the throw pattern. The cones are rotated around a central axis, until the required narrow (or wide) supply air jet is achieved.

Material

The diffuser is manufactured in two sections, an outer sleeve and two inner concentric cones. Finished with an epoxy-painted white (RAL 9010) standard colour).

Accesories

It is recommended that the TRS be used in conjunction with a TRI balancing plenum.

Specification

The Halton TRS shall be furnished and installed where shown on the working drawings. The diffuser shall be made of epoxy-painted steel with a white (RAL 9010) standard colour. The diffuser shall be made in two sections, an outer sleeve and two inner concentric cones.
