The SFRD/SCRD is a circular ceiling diffuser with a graceful exterior, designed with a machine mould formed square frame to suit standard tile size suspended ceiling. The diffuser matches all ceiling fittings, round or square, popular for modern architectural design. The circular diffusion face and cores offer a 360 Degree horizontal or vertical air diffusion pattern, suitable for ceiling height from 2.6m up to 10.5m. It ensures maximum airflow at minimum noise level. SFRD / SCRD can be used in supply, return and exhaust air in cooling, heating and ventilation systems.

Material

• Aluminium (Machine mould formed) (SFRD-A / SCRD-A)
• Steel (Machine mould formed) (SFRD-S / SCRD-S)

Finish

White powder coated as standard. Other finishes are available as options.

Features

• SFRD / SCRD equips with a square face and round neck, suitable for tile size suspended ceiling or other type of ceilings.
• Centre core is removable providing access to air duct accessories and for easy installation.
• Centre core is adjustable to provide the choice of horizontal and vertical air pattern.
• Optional frame for selection. (SFRD or SCRD)
